PP RC (Polypropylene Random Copolymer) from raw materials produced in accordance with international and national quality standards Fırat PPRC Pipes and Fittings; smooth and slick structure, scaling and corrosion, not to have been indispensable solution in the interior of the building with its advantageous aspects such as the ease of installation and hygienic hot and cold water supplies.
When used in appropriate pressure and temperature operating life of Fırat PPRC Pipes and Fittings for over 50 years.
- -20 ° C from and 25atm pressure in the operating life of 50 years.
- -20 ° C to + 95 ° C are suitable for use in the range. (Freezing of the fluid inside the pipe insulation should be applied taking into account.)
• It shows high resistance to chemicals.
• Corrosion resistant. Arthritis and does not rust.
• Water the color does not change the smell and taste.
• Slippery and it has a bright interior.
• diameter contraction does not occur in the welds. It Shows High welding performance.
• Installation is no wastage.
• It is difficult to ignite.
• Environmentally friendly.
| Temperature (°C) | Service Life (Year) | Operation Pressure (Bar) |
|---|---|---|
| 20 | 1 | 30.0 |
| 5 | 28.1 | |
| 10 | 27.3 | |
| 25 | 26.5 | |
| 50 | 25.7 | |
| 30 | 1 | 25.5 |
| 5 | 23.9 | |
| 10 | 23.2 | |
| 25 | 22.3 | |
| 50 | 21.8 | |
| 40 | 1 | 21.5 |
| 5 | 20 2 | |
| 10 | 19.6 | |
| 25 | 18.8 | |
| 50 | 18.3 | |
| 50 | 1 | 18.3 |
| 5 | 17.0 | |
| 10 | 16.5 | |
| 25 | 15.9 | |
| 50 | 15.4 | |
| 60 | 1 | 15.4 |
| 5 | 14.3 | |
| 10 | 13.8 | |
| 25 | 13.3 | |
| 50 | 12.7 | |
| 65 | 1 | 14.6 |
| 5 | 13.6 | |
| 10 | 13.1 | |
| 25 | 12.6 | |
| 50 | 11.1 | |
| 70 | 1 | 13.0 |
| 5 | 11.9 | |
| 10 | 11.7 | |
| 25 | 10.1 | |
| 30 | 8.8 | |
| 50 | 8.5 |
Referans Standart:DIN 2000
| Service Period | Temperature (°C) | Service Life (Year) | Operation Pressure (Bar) |
|---|---|---|---|
| 30 days/year | 75 | 5 | 17.27 |
| 10 | 13 79 | ||
| 25 | 11.74 | ||
| 45 | 10.18 | ||
| 80 | 5 | 13.50 | |
| 10 | 13.80 | ||
| 25 | 11.14 | ||
| 42.5 | 9.79 | ||
| 85 | 5 | 12.42 | |
| 10 | 11.87 | ||
| 25 | 10.14 | ||
| 37.5 | 9.18 | ||
| 90 | 5 | 11.39 | |
| 10 | 10.94 | ||
| 25 | 8.86 | ||
| 35 | 8.16 | ||
| 60 days/year | 75 | 5 | 14.11 |
| 10 | 13.57 | ||
| 25 | 11.58 | ||
| 45 | 10 05 | ||
| 80 | 5 | 13.12 | |
| 10 | 12.54 | ||
| 25 | 10.56 | ||
| 40 | 9.41 | ||
| 85 | 5 | 12.03 | |
| 10 | 11.52 | ||
| 25 | 9.22 | ||
| 35 | 8.48 | ||
| 90 | 5 | 11.04 | |
| 10 | 9.76 | ||
| 25 | 7.81 | ||
| 30 | 7.46 | ||
| 90 days/year | 75 | 5 | 14.02 |
| 10 | 13.38 | ||
| 25 | 11.33 | ||
| 45 | 9.82 | ||
| 80 | 5 | 12 90 | |
| 10 | 12.35 | ||
| 25 | 10.05 | ||
| 37.5 | 9.08 | ||
| 85 | 5 | 11.81 | |
| 10 | 10 72 | ||
| 25 | 8.58 | ||
| 32.5 | 8.03 | ||
| 90 | 5 | 10 59 | |
| 10 | 8.96 | ||
| 25 | 7.17 |
